Hydraulic power tong is a workover tool that utilizes the power of the drilling rig to remove the workover tool. The advantages are obvious and easy to use.

Drilling process in the operation of the largest workers, the most heavy workload is on, unloading pipe fittings and drill thread, in the past has been with a pipe clamp or chain clamp, not only labor-intensive, and dangerous. Hydraulic power clamp is the use of oil rig power operation of the mechanical, unloading deduction tool, can greatly reduce the labor intensity of the workers to avoid or reduce the occurrence of injury accidents. At the same time, hydraulic power tongs to strengthen the pipe, drill wire twist torque, reduce the pipe, drilling tool trip accident occurred. The working principle of the hydraulic power clamp is to pass the power of the drilling rig to the hydraulic power clamp hydraulic motor by the stroke reducer, and then by two or one deceleration, the jaw opening gear rotation, resulting in two high and low speed, Pipe tool (drill) rotation. When the opening gear rotates, the plate frame does not rotate under the braking action of the brake hammer, so that there is a relative movement between the opening gear and the palmar plate. In this way, the two rollers of the palmar plate will climb on the slope plate and force the clamp on the hips board to move toward the center of the pipe (drill) until it is clenched with the tool and then with the opening gear Together drive the pipe (drill) to rotate.

SCOTON's Featured Products (Power Tongs for Sale)

Ⅰ SKT SERIES DUAL-PURPOSE POWER TONGS

SKT series dual-purpose power tongs is applicable to tripping operation and running-in casing operation in the drilling activities in petroleum and mining. It is a new power tongs dependently developed by ourselves according to the requirements from oilfield customers. The power tong integrates the function of drill pipe power tong and casing power tong. It can meet the requirements under the operation of frequent tripping or connecting single pipe. In addition, it can be used to run in the casing with small diameter. During the conversion between the two operations, it is not necessary to replace the equipment. It can increase the wellhead operation efficiency and reduce the labor intensity.

Model

SKT203-100/35

SKT203-100/35Ⅲ

SKT203-125/35

SKT203-125/35Ⅲ

Size range

Drill pipe

mm

127-203

127-203

127-203

127-203

in

31/2"~5 1/2"、8"

31/2"~51/2"、8"

31/2"~51/2"、8"

31/2"~51/2"、8"

Casing

mm

127-196

127-196

127-196

127-196

in

5"~7"

5"~7"

5"~7"

5"~7"

Max.torque

Drill pipe

kN.m

100

100

125

125

ft.lbf

73760

73760

92200

92200

Casing

kN.m

35

35

35

35

ft.lbf

25816

25816

25816

25816

Speed(High gear)

rpm

40

40

40

40

Speed(Low gear)

rpm

2.7

2.7

2.7

2.7

Air pressure

MPa

0.5-0.9

psi

72-130

Pressure rating

MPa

16.6

16.6

20.7

20.7

psi

2400

2400

3000

3000

Flow rating

L/min

114

114

114

114

gpm

30

30

30

30

Shifting distance

mm

0—1500

0—1500

in

0—59

0—59

Travel distance

mm

0-3000

0-3000

in

0-118

0-118

Lifting distance

mm

0-800

0-800

in

0-1.5

0-31.5

Size

mm

1760×1000×1360

1760×1830×2050

1760×1050×1475

1760×1830×2050

in

64.6×71.7×80.7

69×71.7×80.7

69×41.3×58

69×71.7×80.7

Weight

kg

2450

3600

2700

3800

lb

5400

7940

5950

8380

Ⅱ Low Stress Power Tong

Low stress hydraulic power tong is applied for unloading 2 3/8"-4 1/2 tubing and 4 1/2"-5 1/2"casing pipe in marine oil filed and well service operation. It's an open-throat designed power tong. It's an improvement basing on absorbing the advantaged product skill of the world, with changing the special clamp head, which can improve the wearness of tube and no indentation, widely used in the marine oil filed, the high sulfur content field for unloading 9 Cr, 13 Cr, 22 Cr, 25 Cr and other special pipe.


  • Product features describe as:1. Master tong with double brake structure, greatly increased the braking force ,which can ensure reliable clamping, preventing from slippage .
  • The machine is a combination of master and backup tong, by operating the multiple valve lever, which can realize the tongs respectively clamping or loosen .
  • Equipped with extend leading bar and gantry back-up bar, can realize the tongs clamping concurrently,facilitate for the sensor installation, to ensure no twisting while processing .Ensure the torque device performs accurately.
  • Back-up tong with double oil cylinder lever clamping structure, may realize tong head clamping pipe surrounded.
  • Equipped with self locking door device is to protect the safety of the operators.
  • The torque automatic control system is optional , the effect would be better if installed .


Model

SKT-WYH power tong

Application Range of Master Tong

2 3/8" - 5 1/2"

Application Range of Backup Tong

2 3/8" - 5 1/2"

High Gear Rated Torque

2950ft.lbs

Low Gear Rated Torque

14752 ft.lbs

High Gear Rotation Speed

28 rpm

Low Gear Rotation Speed

5 rpm

Rated Operation Pressure

2610 psi

Max. Flow

32 gpm

DimensionL x W x H (in)

51×31×47

Combined Tong Weight(With Backup)

2000 lbs

Ⅲ Close-head Power Tong


  • Close-head power tong is used for quick make-up/break-out in well service operations. the tongs have the following features:
  • Without changing any part within 2 3/8"~3 1/2"
  • Long service life
  • Model CPT89/8 and CPT178/8 are chain-drive tong, it doesn't need to stop working when shift.
  • ModelCPT89/8、CPT178/8 and CPT178/16A are gear-drive tong.


Model

CPT89/8

CPT89/8A

CPT178/8

CPT178/8A

CPT178/16A

Range

Φ60-89

2 3/8’’ - 3 1/2’’

Φ60-89

2 3/8’’ - 3 1/2’’

Φ33.3-178

1 5/16’’ - 7’’

Φ33.3-178

1 5/16’’ - 7’’

Φ33.3-178

1 5/16 - 7’’

High Gear Rated of Torque

1700 N.m

1250 ft·lbs

2400 N.m

1770 ft·lbs

1763 N.m

1300 ft·lbs

1763 N.m

1300 ft·lbs

2000 N.m

1500 ft·lbs

Low Gear Rated of Torque

8100N.m

6000ft·lbs

8100N.m

6000ft·lbs

8100N.m

6000ft·lbs

8100N.m

6000ft·lbs

16000N.m

12000ft·lbs

High Gear Rated speed

126 RPM

82 RPM

126 RPM

126 RPM

130 RPM

Low Gear Rated  speed

27 RPM

22 RPM

27 RPM

27 RPM

19 RPM

Rated Operation Pressure

14 Mpa

2000 PSI

14 Mpa

2000 PSI

14 Mpa

2000 PSI

14 Mpa

2000 PSI

14 Mpa

2000 PSI


Rated Flow

126 LPM

33.5 GPM


120 LPM

32 GPM

127 LPM

33.5 GPM

127 LPM

33.5  GPM

148 LPM

39 GPM

Dimension;LWH

1054×534 ×650

41.5’’×21’’ ×25.5’’

1100×590 ×815

4304’’×23.4’’ ×32’’

1295×762×660

51’’×30’’ ×26’’

1295×762 ×815

51’’×30’’ ×32’’

1549×699 ×1016

61’’×27.5’’ ×40’’

Weight

454 kg

1000 lbs


480 kg

1060 lbs

455 kg

1000 lbs

500 kg

1100 lbs

618 kg

1360 lbs
