Multi-cycle Circulating Subs

Description of Multi-cycle Circulating Subs

The multi-cycle circulating sub is the company's own research and development of new products,The multi-cycle circulating sub has been in the Middle East oil field for a rigorous experiment, and has been used down several times, the customer has a good performance of multi-cycle circulating subs.

The multi-cycle circulating sub is a sub to provide cycle and cooperate by dropping the ball several times. It is an ideal for use in high angle and horizontal wells.

Specification of Multi-cycle Circulating Subs

Model

OD

mm(in)

ID

mm(in)

Conn.

OAL

mm(in)

SMCCS121

121(4-3/4)

45(1-3/4)

NC38

2705(106-1/2)

SMCCS165

165(6-1/2)

63.5(2-1/4)

NC50

3445(135-5/8)

SMCCS178

178(7)

63.5(2-1/4)

NC50

3445(135-5/8)
